Key Features & Selling Points

• Uses the ICLIC engagement system with a pre-open blade spring—makes clipping in very easy.

• Composite (carbon-filled) body for light weight and durability.

• Steel axle / spindle (durable).

• Three tension settings (via carbon blade) to adjust how tight the pedal grips the cleat.

• Low stack height (14.7 mm) for better clearance and more direct power transfer.

• Angular float: +5° / –5° with free (floating) cleats; 0° float when using fixed cleats.

• Lateral freedom: +1.25 mm or –1.25 mm.

• Release angle: approx 16° (free cleats)

• Contact surface area: ~ 700 mm²

• Threading: 9/16"-20 (standard road pedal threading)

• Intended use: road / performance cycling

• Color options in Xpresso line include yellow / fluorescent / “fluro yellow” / “fluoro” variants among others

---

Weights & Measurements

• Weight (per pedal): approx 115 g

• Stack height: 14.7 mm

• Distance from spindle to crank (Q-factor offset / pedal-crank distance): “Regular 53 mm”
