PRAXIS - ROAD 110 BCD 1x NARROW WIDE



Whether you’re cyclocrossing in mud or gravel grinding a fireroad...Praxis 110-BCD 1X rings are ready for action with our new Narrow/Wide tooth profile.



PRODUCT	1X 110mm Bolt Circle Diameter Chainrings
INTRUCTIONS	VIEW MANUAL HERE
BUY THIS IF :	You are wanting to change gearing or refresh the 1X ring on your current 5-ARM 110BCD road/CX crank.
DESIGN STYLE	Please see all photos above... New 110BCD 1X Design
MFG	Forged & Machined | 7075-T6 Aluminum | Hard Blk Anodized Narrow/Wide tooth profile
GEARING	110BCD - 38T / 40T / 42T / 46T 110BCD E-Rings - e44T / e46T Threaded eRing (See Note below!)
AVG. WEIGHT	42T = 72g (Ref. ring)
CHAIN	10 / 11 /12/sp Compatible | Shimano/SRAM/KMC
DRIVETRAIN	SHIMANO -Compatible with both Di2 and mechanical Shimano 10/11/12sp. SRAM -Compatible with both electronic and mechanical SRAM 10/11/12sp. CAMPY - Not compatible with Campy 10/11/12/13sp.
POWER	Compatible with 110BCD spider-based power meters such as Power2Max, SRM and Quarq
NOTE!	eRING - e44T & e46T are Threaded. These E-rings are threaded and require M8 Male Bolts for installation  (For Trek Domane+ & Specialized Creo eBikes)
TECHNOLOGY	Narrow Wide tooth profile
